3.2V 100Ah LiFePO4 Battery Cell
Product Specifications
Nominal Voltage: 3.2V
Rated Capacity: 100Ah (0.5C, 25°C)
Energy: 320Wh
Cycle Life: 5000 cycles (80% DOD, 80% EOL)
Charge Voltage: 3.65V
Max Charge Current: 100A
Max Discharge Current: 300A
Operating Temp (Charge): 0°C to 55°C (32°F to 131°F)
Operating Temp (Discharge): -20°C to 60°C (-4°F to 140°F)
Storage Temp: -25°C to 65°C (-13°F to 149°F)
Dimensions: 260 x 169 x 211 mm (10.6 x 6.9 x 8.6 in)
Weight: 1.93 kg (4.25 lbs)
Certifications: MSDS, UN38.3, FCC, PSE, CE, UKCA, RoHS, REACH, Halogen Free
Warranty: 1-year material warranty
| Category | Specification | Category | Specification |
| Rated Capacity | 100 Ah (0.5C, 25°C) | Charge Temp | 32°F to 131°F / 0°C to 55°C |
| Nominal Voltage | 3.2V | Discharge Temp | -4°F to 140°F / -20°C to 60°C |
| Energy | 320Wh | Storage Temp | -13°F to 149°F / -25°C to 65°C |
| Cycle Life | 5000 Cycles (80% DOD) | Humidity | 10% to 95% |
| Charge Voltage | 3.65V | Dimension | 260 x 169 x 211 mm |
| Max Charge Current | 100 A | Weight | 4.25 lb / 1.93 kg |
| Max Discharge Current | 300 A | Packing | 10PCS/Box |
| Certifications | MSDS, UN38.3, CE, UKCA | Warranty | 1 Year |
Product Description
Engineered for durability and efficiency, this 3.2V 100Ah LiFePO4 battery is built to withstand rigorous daily use. Its high discharge rate of 300A makes it suitable for high-power applications, while its wide operating temperature range ensures stable performance in both cold and hot environments.
Core Advantages
- ✅Long Lifespan: Over 5000 charge-discharge cycles.
- ✅High Power Output: Supports 300A continuous discharge.
- ✅Wide Temp Tolerance: Operates from -20°C to 60°C.
- ✅Safe Chemistry: LiFePO4 technology for superior stability.
- ✅Global Certs: Compliant with MSDS, UN38.3, CE, UKCA, RoHS.
Perfect For
☀️ Solar energy storage systems
🚗 Electric vehicles and e-bikes
🚤 RV and marine power banks
🔋 Backup power for telecom and UPS
🛠️ DIY battery pack projects
Customization Available
We offer OEM/ODM services for battery packs, including custom voltage, capacity, and housing design. Contact us to tailor a solution that fits your specific application needs.
