48V 50Ah Rack-Mounted LiFePO4 Battery
Product Specifications
Nominal Voltage: 48.0V
Rated Capacity: 50Ah
Total Energy: 2400Wh
Cycle Life: 5000 Cycles (at 80% DOD, 80% EOL)
Dimensions (LxWxH): 482 x 410 x 98 mm (18.97 x 16.14 x 3.85 in)
Weight: 23.5 kg (51.5 lb)
Protection Rating: IP20
Certifications: CE, UN38.3, RoHS，MSDS
48V 50Ah Rack-Mounted LiFePO4 Battery (2400Wh)
Compact 19-Inch Energy Storage for UPS & Telecom
Engineered for reliability and space efficiency, this rack-mounted battery is the ideal power solution for modern data centers, telecommunications hubs, and commercial UPS systems. Its robust design features a standard 19-inch form factor, allowing for easy installation and scalability in any server rack environment. The advanced LiFePO4 chemistry ensures superior thermal and chemical stability, providing a safe and maintenance-free power source. With a high 5000-cycle life, this battery minimizes long-term replacement costs and operational downtime, making it a smart investment for any business.
Core Advantages
- Space-Saving Rack Design: The compact, standard 19-inch form factor allows for easy installation and maximizes space efficiency in server racks and network cabinets.
- Exceptional Longevity: Engineered for over 5000 deep discharge cycles, this battery offers a significantly longer lifespan compared to traditional lead-acid batteries, reducing total cost of ownership.
- High Power Output: Capable of delivering a continuous 25A charge and discharge current, with a peak of 100A, ensuring stable power for high-demand applications.
- Inherent Safety: The use of stable LiFePO4 cells provides excellent thermal and chemical stability, making it a very safe battery option with a low risk of overheating.
Technical Specifications
| Parameter | Specification |
|---|---|
| Nominal Voltage | 48.0V |
| Rated Capacity | 50Ah (0.5C, 25°C) |
| Total Energy | 2400 Wh (2.4 KWh) |
| Cycle Life | 5000 Cycles (80% DOD, 80% EOL) |
| Charge Voltage | 54.75V |
| Max Continuous Charge Current | 25A |
| Max Continuous Discharge Current | 50A |
| Peak Discharge Current | 100A @ 3S |
| Charge Temperature | 0°C to 45°C |
| Discharge Temperature | -20°C to 60°C |
| Storage Temperature | -10°C to 50°C |
| Relative Humidity | 10% to 90% |
| Dimensions (LxWxH) | 482 x 410 x 98 mm (18.97 x 16.14 x 3.85 in) |
| Weight | 23.5 KG (51.5 lb) |
| Protection Rating | IP20 |
Perfect For
- Data Center UPS: Provides reliable backup power for servers, network switches, and other critical IT infrastructure.
- Telecommunications: Ideal for base stations and communication equipment requiring stable, long-duration power.
- Commercial & Industrial Energy Storage: Can be integrated into larger systems for peak shaving, load shifting, and backup power.
- Medical Facilities: Ensures uninterrupted power for sensitive medical equipment.
Customization Services
We understand that every project has unique requirements. Our customization services are available to tailor this battery solution to your specific needs:
- Custom Cabling & Connectors: Adapting terminal types and cable lengths for your specific setup.
- Branding & Labeling: Adding your company logo and custom labels.
- System Integration Support: Providing technical assistance for integrating the battery into your existing power system.
